Allen-Bradley PowerFlex Drives
Set up and wire Allen-Bradley PowerFlex drives, then link them to a Logix PLC over EtherNet/IP, using the free CCW software.
Allen-Bradley PowerFlex Drives is a free, self-paced online course from EDWartens for engineering students, apprentices, technicians and working engineers in electrical and automation maintenance. It has 10 modules and takes about 15.8 hours, with written notes, a practice task per module, a practical project and a final assessment of 15 questions (pass mark 60%). Learning costs nothing and needs only a free account. The optional EDWartens Certificate of Completion, verifiable by code, is a one-off US$23.99 for you; it is not a vendor credential. Updated 1 November 2026.
- Free
- Beginner
- 15.8 hours
- Self-paced
- Certificate optional
- Lab practice in your browser
No card, no trial. The course is free for good. Certificate US$23.99, optional.
- Who it is for
- Engineering students, apprentices, technicians and working engineers in electrical and automation maintenance
- Jobs
- Roles that use this skill: drives engineer, motion control engineer, service technician and commissioning engineer. No course guarantees a job.
- Tools
- Connected Components Workbench Standard (free); Studio 5000 Logix Designer is paid and needed only for the EtherNet/IP module. Hardware: none required. A PowerFlex 525 makes the wiring modules real.
- Updated
After this course you can
By the end you will be able to:
- Set PowerFlex 525 parameters from the keypad and from CCW
- Wire 2-wire, 3-wire, reverse and analog speed control
- Connect a drive to a Logix PLC over EtherNet/IP
- Use encoder feedback, PID, StepLogic and Safe Torque Off on the 525
- Set up a PowerFlex 4 and know where the 750 series differs
Who it is for, and what you need first
Who it is for
Engineering students, apprentices, technicians and working engineers in electrical and automation maintenance.
Level: Beginner. Beginner to intermediate. The free VFD course is the ideal preparation.
What you need
Software: Connected Components Workbench Standard (free); Studio 5000 Logix Designer is paid and needed only for the EtherNet/IP module.
Hardware: None required. A PowerFlex 525 makes the wiring modules real.. What to download, and how.
How this course works
Watch the lessons
Short video lessons, one module at a time, at your own pace.
Read the notes
Open the Reading tab for the written notes and diagrams of the module.
Practise in the 3D labOptional
Try the module in the free 3D lab, in your browser.
Check yourself
Answer the questions to see what stuck before you move on.
Final assessment
Pass the final once you have been through the modules.
Certificate, if you want oneOptional
Optional, with a page anyone can use to verify it.
What you learn
10 modules in order, at your own pace. 15.8 hours of video lessons, with written notes and a practice task in each module.
- 1The PowerFlex Family and VFD Fundamentals1h 45m
- 2PowerFlex 525: Keypad, Parameters, Wizard, Faults and Reset38m
- 3Wiring: 2-Wire, 3-Wire, Reverse, Potentiometer and Analog, with lab practice: 48m
- 4Connected Components Workbench for PowerFlex1h 44m
- 5EtherNet/IP with Logix: Adding the Drive, ADC, Start, Stop and Speed, with lab practice: 2h 30m
- 6Encoder, PID, StepLogic and STO on the 525, with lab practice: 24m
- 7PowerFlex 4 and 4M47m
- 8PowerFlex 750 Series and 755TS43m
Show the other 2 modules
- 9Armor PowerFlex, MCCs, Line Reactors and IEEE 51948m
- 10Final Assessment
Software you need
What to download, where from, what it costs and how to install it. Every link goes to the maker's own site, never a mirror.
Show what to download (2 tools)
Required
- 01Free
Connected Components Workbench Standard Edition
Rockwell Automation
- Runs on
- Windows 10 or 11 Pro or Enterprise 64-bit, or Windows Server 2019/2022
- Account
- A free Rockwell Automation account (sign in to the Product Compatibility and Download Center)
The Standard Edition is free and needs no activation. It includes a demo version of the Micro800 Simulator; the full simulator comes with the paid Developer Edition.
Steps
- 1.Open the Connected Components Workbench page on the Product Compatibility and Download Center.
- 2.Click Available downloads next to the latest version (23.00.00 on 27 Sept 2026) and sign in.
- 3.Accept the licence agreement and download the installer.
- 4.Run the setup as administrator; it installs .NET Framework 4.8 if needed.
- 5.Start Connected Components Workbench, add a Micro800 controller and open the Micro800 Simulator to test your program.
- Rockwell lists 8 GB RAM and 20 GB free disk as the minimum.
- The installer does not work on the very first Windows 10 releases (1507 and 1511); update Windows first.
Official download pagecompatibility.rockwellautomation.comAlternatives
- FactoryTalk Design Workbench: Rockwell's newer free Micro800 design tool.
Optional
Useful, not needed to finish the course.
- 02Paid only
Studio 5000 Logix Designer
Rockwell Automation
- Runs on
- Windows (check the Studio 5000 entry on the Product Compatibility and Download Center for exact versions)
- Account
- A Rockwell Automation account plus a purchased licence (serial number or subscription)
Rockwell sells Studio 5000 Logix Designer as a perpetual licence or a paid subscription. Rockwell's product page offers no public free trial or free edition.
Steps
- 1.If your employer or college has a Studio 5000 licence, ask for access and the serial number.
- 2.Sign in to the Rockwell Product Compatibility and Download Center and search for Studio 5000 Logix Designer.
- 3.Download the version that matches your controller firmware.
- 4.Install it as administrator and activate the licence with FactoryTalk Activation Manager.
- 5.If you have no licence, use one of the free Rockwell tools listed below instead.
- Match the Logix Designer major version to the controller firmware you will use.
Rockwell Automation product pagerockwellautomation.comLegitimate free routes
- Connected Components Workbench Standard Edition: Free. Programs Micro800 controllers and includes a demo Micro800 Simulator.
- FactoryTalk Design Workbench: Free Rockwell tool for Micro800 controllers, listed with the free downloads on PCDC.
- RSLogix Micro Starter Lite: Free edition for MicroLogix 1000 and 1100.
- FactoryTalk Design Studio free trial: Rockwell's cloud-based Logix design software with a free 90-day trial in the browser.
- Rockwell Automation training: Instructor-led Studio 5000 courses; an employer licence is the other legitimate route.
Checked against each maker's own page on 27 September 2026. Trial lengths and editions change; the maker's page is the final word.
Practise in the 3D lab
Wire a variable frequency drive in the Panel Lab, with safe torque off, a run command and a speed signal, and write the matching PLC start and stop logic.
- Motor start/stop with overloadPLC lab, about 45 minOpen in the lab (opens in a new tab): Motor start/stop with overload
- Commission the variable-speed infeed conveyor driveElectrical labOpen in the lab (opens in a new tab): Commission the variable-speed infeed conveyor drive
Optional. Skip it whenever you like: it never blocks your progress or your certificate.
Course project, about 10 hours
Humidification fans: six PowerFlex 525 drives, from motor list to energy report
Choose and set up PowerFlex 525 drives for a spinning mill's humidification fans, and prove the saving with the cube law. You deliver a selection table, a parameter record, control logic, a Safe Torque Off sketch, a commissioning plan and an energy report.
- 8documents in the pack
- 8steps to follow
- 6things to hand in
- 10 hof work, at your pace
- Motor listMotor List: Humidification Plants HP-1, HP-2 and HP-3
- Load listElectrical Load List: VFD Panel HUM-VFD-1
- MCC scheduleMCC Schedule: VFD Panel HUM-VFD-1
- Single lineSingle Line Diagram: HUM-VFD-1 and its feeder from LV-2 (described)
- Drive parameter listDrive Parameter Record: Six PowerFlex 525 on HUM-VFD-1
- FATFactory Acceptance Test Record: VFD Panel HUM-VFD-1
The project is optional practice. The certificate needs only the modules and the final assessment.
