Siemens TIA Portal PID Compact and Analog Processing
Scale analog signals and run a PID_Compact control loop in TIA Portal, tested against a tank simulation.
Siemens TIA Portal PID Compact and Analog Processing is a free, self-paced online course from EDWartens for engineering students, apprentices, technicians and working engineers in process plants. It has 7 modules and takes about 5.3 hours, with written notes, a practice task per module, a practical project and a final assessment of 15 questions (pass mark 60%). Learning costs nothing and needs only a free account. The optional EDWartens Certificate of Completion, verifiable by code, is a one-off US$28.99 for you; it is not a vendor credential. Updated 1 November 2026.
- Free
- Intermediate
- 5.3 hours
- Self-paced
- Certificate optional
- Lab practice in your browser
No card, no trial. The course is free for good. Certificate US$28.99, optional.
- Who it is for
- Engineering students, apprentices, technicians and working engineers in process plants
- Jobs
- Roles that use this skill: instrumentation technician, instrument engineer, calibration technician and process control engineer. No course guarantees a job.
- Tools
- The current TIA Portal trial (21 days) with S7-PLCSIM, on 64-bit Windows 11 Pro or Enterprise; Factory I/O (30-day trial) for the level scene. Hardware: none. The tank simulation and Factory I/O stand in for the plant.
- Updated
After this course you can
By the end you will be able to:
- Explain why a loop needs a controller and what P, I and D do
- Scale analog inputs and outputs
- Place and configure PID_Compact in a cyclic OB
- Tune the loop with pretuning and fine tuning
- Run the loop against an HMI and a tank simulation
Who it is for, and what you need first
Who it is for
Engineering students, apprentices, technicians and working engineers in process plants.
Level: Intermediate. Intermediate. You should already write ladder in TIA Portal; the Siemens TIA Portal foundation course is the ideal preparation.
What you need
Software: The current TIA Portal trial (21 days) with S7-PLCSIM, on 64-bit Windows 11 Pro or Enterprise; Factory I/O (30-day trial) for the level scene.
Hardware: None. The tank simulation and Factory I/O stand in for the plant.. What to download, and how.
How this course works
Watch the lessons
Short video lessons, one module at a time, at your own pace.
Read the notes
Open the Reading tab for the written notes and diagrams of the module.
Practise in the 3D labOptional
Try the module in the free 3D lab, in your browser.
Check yourself
Answer the questions to see what stuck before you move on.
Final assessment
Pass the final once you have been through the modules.
Certificate, if you want oneOptional
Optional, with a page anyone can use to verify it.
What you learn
7 modules in order, at your own pace. 5.3 hours of video lessons, with written notes and a practice task in each module.
- 1Why Closed-Loop Control, and What P, I and D Mean29m
- 2Analog Input Processing: NORM_X and SCALE_X, with lab practice: 25m
- 3Analog Output Processing: Unscaling20m
- 4PID_Compact: Placing, Configuring and Running It18m
- 5Tuning PID_Compact, and Analog versus PWM Output, with lab practice: 34m
- 6Tank Simulation, HMI Control and Factory I/O Level Control, with lab practice: 37m
- 7Final Assessment
Software you need
What to download, where from, what it costs and how to install it. Every link goes to the maker's own site, never a mirror.
Factory I/O is for the level scene only.
Show what to download (3 tools)
Required
- 01Free trial: 21 days
SIMATIC STEP 7 Professional and WinCC (TIA Portal) V21 Trial
Siemens
- Runs on
- Windows 11 Pro or Enterprise 64-bit (24H2), Windows 10 Enterprise 2021 LTSC, or Windows Server 2022/2025. Windows 11 Home is supported only for the Basic editions.
- Account
- A free Siemens account registered for Industry Online Support (SiePortal)
- Size
- about 8.1 GB for the main ISO, plus an optional 3.1 GB DVD 2 with hardware support packages
Siemens lets registered users download the V21 trial of STEP 7 (Basic and Professional), STEP 7 Safety and WinCC and test it for 21 days. The same package is used for the full product; after 21 days you need a purchased licence to keep working.
Steps
- 1.Open the Siemens trial page (entry 109989774) and sign in with your Siemens Industry Online Support account.
- 2.Download TIA_Portal_STEP7_Safety_WinCC_V21.iso (8.1 GB).
- 3.Download S7-PLCSIM_V21.iso (2.5 GB) from the same page: PLCSIM is a separate download.
- 4.Right-click each ISO, choose Mount, and run Start.exe as administrator. Install STEP 7 and WinCC first, then PLCSIM.
- 5.Follow the setup, accept the licence terms and restart the PC when asked.
- 6.Open TIA Portal V21 and create a new project to confirm it runs.
- Install from a local drive with plenty of free space; Siemens lists 20 GB free as the minimum and the ISOs alone are over 10 GB.
- You only need DVD 2 if you want extra hardware support packages.
- If you cannot install locally, Siemens also offers a 21-day TIA Portal Cloud trial in the browser (one-hour sessions, not in every country).
Official download pagesupport.industry.siemens.comAlternatives
- TIA Portal Cloud trial: 21 days free in a cloud virtual machine, no install. Sessions are limited to one hour and it is not available in every country.
- 02Free trial: 21 days
S7-PLCSIM V21 (TIA Portal) Trial
Siemens
- Runs on
- Windows 11 Pro or Enterprise 64-bit (24H2), Windows 10 Enterprise 2021 LTSC, or Windows Server 2022/2025. Windows 11 Home is supported only for the Basic editions.
- Account
- A free Siemens account registered for Industry Online Support (SiePortal)
- Size
- about 2.5 GB (ISO)
S7-PLCSIM V21 is offered as a 21-day trial on the same Siemens page as the STEP 7 and WinCC V21 trial. It needs STEP 7 V21 installed on the same PC.
Steps
- 1.Open the Siemens STEP 7 and WinCC V21 trial page (entry 109989774) and sign in.
- 2.Install STEP 7 V21 from the main TIA Portal ISO first.
- 3.Download S7-PLCSIM_V21.iso (2.5 GB) from the section Download S7-PLCSIM Standard V21.
- 4.Mount the ISO, run Start.exe as administrator and follow the setup.
- 5.In TIA Portal, select your CPU and click Start simulation to open PLCSIM.
- Siemens notes that the PLCSIM Standard V21 installation also includes S7-PLCSIM Advanced V8.0.
Official download pagesupport.industry.siemens.com
Optional
Useful, not needed to finish the course.
- 03Free trial: 30 days
Factory I/O
Real Games
- Runs on
- Windows 7 SP1 or newer, with a graphics card from 2006 (NVIDIA, AMD) or 2012 (Intel) onwards
- Account
- Your name and email on the Factory I/O trial form
The 30-day trial includes the full Ultimate Edition. After that you need a paid edition; the Siemens, Allen-Bradley, Modbus and OPC, MHJ, Automgen and Starter editions each support different PLCs.
Steps
- 1.Open the Factory I/O start trial page.
- 2.Enter your name and email and start the trial.
- 3.Download and install Factory I/O.
- 4.Open a sample scene and connect it to your PLC or PLC simulator.
- 5.Before the trial ends, choose the edition that matches your PLC.
- Choose the edition by the PLC you will use: for example the Siemens edition works with S7-PLCSIM.
- The Starter edition has its own built-in PLC simulator if you have no PLC software.
Official download pagefactoryio.com
Checked against each maker's own page on 27 September 2026. Trial lengths and editions change; the maker's page is the final word.
Practise in the 3D lab
Practise analog scaling, a broken-loop check and PID tuning in the lab, the same ideas you set up with NORM_X, SCALE_X and PID_Compact.
- Loop checkProcess lab, about 35 minOpen in the lab (opens in a new tab): Loop check
- Commission the 4-20 mA level loopElectrical labOpen in the lab (opens in a new tab): Commission the 4-20 mA level loop
- Tune the level loopProcess lab, about 45 minOpen in the lab (opens in a new tab): Tune the level loop
Optional. Skip it whenever you like: it never blocks your progress or your certificate.
Course project, about 18 hours
Pasteuriser outlet temperature and balance-tank level: two PID_Compact loops on an S7-1200, tuned and recorded
Program, tune and document two control loops for a dairy pasteuriser: heat-exchanger outlet temperature and balance-tank level, each run by PID_Compact in a cyclic OB on an S7-1200. You deliver the program, loop-check sheets, a FAT record and a tuning record. If you have time, you also write your own control description and I/O list. The sample pack shows every document the way an integrator hands it over. Steps 1 and 2 are optional, but without them the most you can score is 70.
- 9documents in the pack
- 9steps to follow
- Laboptional: in the 3D lab
- 5things to hand in
- 18 hof work, at your pace
- P&IDP&ID Tag and Line Schedule: Pasteuriser Heating Section PAS-1
- Control narrativeControl Narrative: PAS-1 Temperature and Level Control
- Instrument indexInstrument Index: PAS-1
- I/O listI/O List: Panel CP-201
- Loop drawingInstrument Loop Diagrams: TT-101, TCV-101, LT-100, LCV-100
- Alarm listAlarm List: PAS-1
Do it in the lab: 4 steps.
The project is optional practice. The certificate needs only the modules and the final assessment.
After the course, your next step
Show what you can do, then keep going in the same field.
A certificate you can verify
